Specification |
Display
|
LCD 128 x 64 dot-matrix, with backlight |
|
Range (Resolution) |
±20μm (0.01μm)
±40μm (0.02μm)
±80μm (0.04μm) |
|
Parameters |
Ra, Rz, Ry, Rq |
|
Display resolution |
0.001 μ m/ 0.04 μ inch |
|
Cutoff Length |
0.25mm / 0.8mm / 2.5mm |
|
Evaluation length |
1~5 cut-off (selectable) |
|
Measuring Range |
Ra: 0.025-12.5μ |
|
Measuring Range |
Rz:
0.02-160μ |
|
Tip Angle |
90° |
|
Vertical rotate |
45mm |
|
Tip Material |
Diamond |
|
Tip radius |
5μm±1μm |
|
Power |
Li-ion battery rechargeable |
|
Digital filter |
RC, PC-RC, GAUSS, D-P |
|
Bores from Diameter |
6.0mm, depth 15mm (TS100) |
|
Accessories |
Soft Carrying Case |
|
|
|
